ใช้เทคโนโลยีการเข้ารหัสดิจิตอล wpa/ WPA2ช่วยให้มั่นใจได้ถึงความเป็นส่วนตัวในการประชุมหลีกเลี่ยงการรบกวนที่เป็นอันตราย
สอดคล้องกับมาตรฐานไร้สาย IEEE802.11ac WAVE-2 /a/b/g/n
การเลือกจุดความถี่หลายจุดของเราเตอร์5G WiFi แบบพกพาจาก UHF, 2.4GHz และ5GHz
ด้วยอินเทอร์เฟซ RJ45สองช่องการเชื่อมต่อ1ช่อง D7301โฮสต์การประชุมการเชื่อมต่ออื่น ap.
แนะนำให้ใช้สาย CAT6ไขว้คุณภาพสูง
การออกแบบสี่เสาอากาศภายนอกทำให้การรับส่งข้อมูลมีเสถียรภาพมากขึ้น
ครอบคลุมสัญญาณในสภาพแวดล้อมที่ซับซ้อนคือรัศมี25เมตรซึ่งสามารถเข้าถึงรัศมี30เมตรได้ตามปกติสำหรับการประชุมทางเสียงแบบไร้สาย
การใช้พลังงานสูงสุด: 15W; ขนาด: 188 × 188 × 40มม.
น้ำหนักสุทธิ: 0.5กก.
Model | D7341 | |
Hardware Specification | ||
Wired interface | 10/100/1000Mbps LAN*2 | |
Wireless bandwidth | 1200Mbps | |
Operating band | 2.4G: 2400Mhz ~ 2483Mhz 5.8G: 5100Mhz ~ 5900Mhz | |
Wireless standards | IEEE802.11ac wave-2 /a/b/g/n | |
Modulation method | OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK | |
Transmit power | 11n 2.4G 25dBm (adjustable) 11n 5G 23dBm (adjustable) 11ac 2.4G 23dBm (adjustable) 11ac 5G 22dBm (adjustable) | |
Antenna gain | 5dBi 2*2 | |
Operating/storage environment | Working temperature: | -10 to 50℃ |
Storage temperature | -40 to 70℃ | |
Humidity (non-concentrated) | ≤90% (non-condensing) | |
Power solution | 48V PoE Power over Ethernet (IEEE802.3af/at) | |
Power consumption | ≤ 15W | |
Installation method | Ceiling mounted | |
Dimensions | 188×188* 40mm | |
weight | 0.5kg | |
Software Specification | ||
The recommended number of accesses | 120 (best user experience) | |
Connection limitation | Support | |
Timed restart | Support | |
Power regulation | Support | |
Channel conditioning | Support | |
Virtual AP | Support the division of up to 8 SSIDs | |
Chinese SSID | Support | |
The SSID hidden | Support | |
Radio frequency disabled | Support | |
Spectrum Navigation | Support, 5G first | |
SSID VLAN | Support, each SSID is divided into different VLANs | |
AP Trace | Support | |
AP Alarm assistance | Support, when the wireless AP detects certain anomalies and cannot recover, it releases a rescue signal with the logged in SOS and the SSID six digits after the AP endorses MAC address; Wireless network maintenance personnel can log in to the AP by connecting the rescue SSID to diagnose the cause of the failure with one click. | |
Channel optimization | Support, channel capacity optimization | |
Load balancing | Support | |
Seamless roaming | Support | |
AP Online Upgrade | Support | |
Cloud AC management | Support | |
Local AC | Support | |
AC is offline | Support. Communication between AC and AP is interrupted, internet access is not affected, and user is unaware | |
Group Management | Support, AP Packet Management | |
IP bulk modification | Support, the management IP of the AP can be modified in bulk in AC | |
Password bulk modification | Support, the AP login password can be modified in bulk in AC | |
Maintenance | Supports on-premises maintenance, cloud maintenance | |
System login | Default IP: 192.168.188.253 Account number: Admin Password: Admin |
