System Indicators | Parameters | |
Frequency Range | 632-695.25MHz | |
Modulation Mode | Wideband FM | |
Adjustable Range | 60MHz | |
Number of Channels | 200 | |
Channel Interval | 250KHz | |
Frequency Stability | Within ±0.005% | |
Dynamic Range | 88dB | |
Maximum Frequency Deviation | ±45KHz | |
Audio Response | 120Hz-16KHz (±3dB) | |
Comprehensive S/N Ratio | >73dB | |
Comprehensive Distortion | ≤1% | |
Operating Temperature | -10°C - +40°C | |
Effective Range | 150-200m (in open environment) | |
Package Dimensions (L×W×H) | 530×335×330mm | |
D5881/D5881L Gross Weight | 9kg | |
D5882/D5883/D5882L/D5883L Gross Weight | 7.4kg | |
D5884/D5884L/D5885L Gross Weight | 9.6kg | |
Receiver | Wireless Connector | BNC/50Ω |
Sensitivity | ≤-95dBm | |
Spurious Suppression | ≥75dB | |
Function Display Mode | Display screen | |
Operating Power | DC12V, 600mA | |
Package Dimensions (L×W×H) | 530×335×145mm | |
Machine Dimensions | 430×176×88mm | |
Gross Weight | 5.2kg | |
Net Weight | 3.3kg | |
